Geometrical Tolerancing to BS 8888 & ISO Standards – Level 1

GD&T ISO Level 1 Course Aim

The course covers the fundamental concepts of geometrical tolerancing and its application and interpretation. The course is suitable for anyone who is familiar with the conventions of engineering drawing and dimensional (or ±) tolerances and is relevant to anyone who has to produce or interpret mechanical engineering specifications.

The course is based on BS 8888 and ISO standards (a version is also available based on the American ASME Y14.5 standard). Delegates are provided with comprehensive course notes, and a workbook with questions and exercises to accompany the training material.

Course Description

Modules:
  • Standards in context
  • Benefits of geometrical tolerancing
  • Features and features of size
  • Linear size and the Envelope Requirement
  • Datums and datums system
  • Tolerance frames
  • Geometrical tolerance characteristics
  • Maximum Material Requirement and Virtual Condition Boundaries.

Who the course is for

  • Designers
  • Engineers
  • Inspectors
  • Technicians
  • Engineering Management





Funding is available for qualifying companies. Find out if you qualify by registering your interest below.

Details

This is a 3-day instructor-led classroom training course

Date: 23rd - 25th of September 2024 (3-day course)

Location: Irish Manufacturing Research, Mullingar, Co Westmeath

Certification / Awarding Body: Engineers Ireland CPD approved for 21 Hours

Course Fees: Supported under the SOLAS Skills to Advance programme subject to eligibility criteria. Register your interest to find out more

Learning Outcomes

  • ISO & ASME: the two systems of standards for mechanical specification
  • The benefits of using Geometrical Tolerancing
  • How Geometrical Tolerancing works (four fundamental geometrical properties)
  • Features and Features of Size
  • Linear size tolerances and the Envelope Requirement
  • Datums and datum features
  • Common datums (based on multiple datum features)
  • Datums systems and the six degrees of freedom
  • How to select and identify datum features
  • The use of datum targets
  • Theoretically Exact Dimensions
  • Tolerance frames
  • Tolerance characteristics & symbols
  • Tolerance frame modifiers (CZ etc.)
  • How to apply geometrical tolerancing in a systematic way
  • Maximum Material Requirement and bonus tolerance
  • Virtual Condition boundaries



See all GD&T Courses


*Limited to 8 places

Register Interest - GD&T ISO Level 1 Course
